Kontron Sigma 5000 Imagic Elite Ultrasound with 3 probes

Cardiology Specialized Ultrasound, Year 2010

Kontron Sigma 5000 Imagic Elite Ultrasound

Included: 3 probes (Sector, Vascular, and Pencil)*

High-quality imaging. Color Doppler

ECG cable for advanced cardiac examinations

The IMAGIC Elite Ultrasound is an expert-class, fully digital system (512 channels) from the Sigma 5000 family. Built on an open and flexible platform, it incorporates advanced technologies and architectures to deliver a new level of diagnostic research:

• Open and flexible PC-based architecture
• FPGA-based digital beamforming
• Fully digital multi-channel signal processing using FCI (Fine Grain Reduction) technology
• TriaX mode and 2nd harmonic imaging (Smart Harmonic) for superior image quality in B-mode (2D), M-mode, and anatomical M-mode
• ATEC Pro mode: Reduces tissue interference and enhances imaging in Color Doppler (CFM) and Power Doppler modes
• Integrated stress echo system
• DFC mode: Maximizes sensitivity in Spectral Doppler (CW and PW)
• Advanced ergonomics for ease of use
• Integrated communication capabilities: TCP/IP – DICOM 3.0
• iCFM (Intelligent CFM): Modern technology that increases frame rates and enhances color resolution and sensitivity in Color Doppler Mapping (CFM) mode

Complete Program Suite:
Covers cardiology and vascular research (including automatic PISA calculation), obstetrics/gynecology, urology, abdominal studies, and superficial structures.

Multifunctional Applications:
Adult and pediatric cardiology (including transesophageal studies), abdominal studies, peripheral vessel and transcranial studies, obstetrics and gynecology, urology and proctology, superficial structures, pediatrics, etc.

Imaging Modes:

• B-mode (2D)
• B-mode pseudocolorization
• 2nd harmonic mode (Smart Harmonic)
• HPRF mode
• M-mode
• M-mode pseudocolorization
• Anatomical M-mode (optional)
• Spectral Doppler (Continuous Wave (CW) and Pulsed Wave (PW))
• Color Doppler (Color Flow Mapping (CFM))
• Power Doppler (PDI)

Combined Modes:

• Dual B-mode on a single screen (study and freeze modes)
• B+CFM (dual image)
• B+DTI (dual image)
• B+M
• Dual CFM images on a single screen (study and freeze modes)
• Duplex: B+M, B+PW/CW, B+CFM, B+PDI, B+TDI, CFM+PW/CW
• Pseudo-triplex mode
• Triplex: B+CFM+PW/CW, B+PDI+PW, B+TDI+PW/CW, B+TDI+M, B+CFM+M
