Aloka Prosound Alpha 10 Ultrasound Obst/Gyn specialty

Aloka SSD-Alpha 10 Ultrasound Machine - Year: 2009

Specialty: Obstetrics and Gynecology

Features: Pulsed Color Doppler

Included Accessories:

• 1 Sony UP-897MD video graphic printer
• 1 convex probe UST-9115-5
• 1 endovaginal probe UST-9118

Signal Processing Technology

• Compound Pulse Wave Generator (CPWG): Enhances focus, spatial resolution, and contrast while reducing artifacts.
• High precision transmission/reception timing: 4 to 8 times more accurate than conventional systems, providing high-resolution beams.

Imaging Modes

• B-mode (grayscale imaging)
• Spectral Doppler (PW, HPRF, CW)
• Color Flow Imaging (Color Flow, PowerFlow, eFlow)
• Real-Time 3D Imaging (optional)
• Combined Mode: Simultaneous display of multiple modes (triplex, Dual Dynamic Display).

Resolution Performance

• Maximum frame rate: Up to 926 fps (depending on settings and probe).
• Grayscale: 256 levels.

Ergonomics and Scalability

• Modular architecture: Supports hardware and software upgrades.
• Designed for intuitive and efficient use.

Data Storage and Management Capabilities

• Cine memory: Up to 16,320 images.
• DICOM compatibility: For archiving and printing.
• Supports internal hard drives, floppy disks, CD-R, and network interfaces.

Specialized Analyses

• Obstetric, cardiac, vascular, and abdominal measurements.
• Tissue analysis: Tissue Doppler Imaging, strain rate.
• Automatic calculation of indices (EF, Volume, IMT).

Monitor and Interfaces

• 17-inch adjustable SVGA monitor.
• Video interfaces: Composite color and black/white, Y/C.
• Connectivity for compatible printers and DVD recorders.

Physical Specifications

• Dimensions: 58 cm (W) × 109 cm (D) × 144–157 cm (H).
• Weight: Approx. 210 kg.
• Power supply: 115/200–240V, 50/60 Hz.
